The textbook in accordance with the program sets out the project method that allows you to build images of spatial geometric images on the plane, ways to solve the main tasks on the drawing, the rules for the image on the drawings of parts and the products collected from them.
The basics of using personal computers are given to solve graphic problems. Widely used production experience. Information is given on adjacent issues of design, technology, measurements. Examples are considered and proposals are given that facilitate the implementation of independent graphic work by students.
For students of Nemashino specialties of higher educational institutions.
10th edition, stereotypical.
Author
Chekmarev Albert Anatolyevich
Editor
Kozlov Vladimir Alexandrovich
Publisher
Higher School, 2008
Series
For higher educational institutions
